Description

GooseNeck Coupler, 2 5/16″ Ball, 25,000 Lbs Capacity, 4.5″ Outer Diameter, Round Tube, 29.2″ Retracted Height, With Load Bearing Pin, 2 Set Screws and 8″ of Adjustment

Product Details

Ram 2 5/16″ Round Adjustable Gooseneck Coupler – 25,000lb Capacity

New cast head design features a one piece coupler casting with a curved internal ball clamp bar. One piece coupler casting allows for greater strength and even better precision fit. curved internal ball clamp bar secures coupler to hitch ball.  This also allows for easier coupling and uncoupling as it does not have a separate bottom plate. Hidden spring latch mechanism within casting for ease of use and protection of moving parts.

Round gooseneck coupler fits 2-5/16″ ball and includes inner and outer tube, 2 set screws and pins – all to ensure a perfect, secure hookup.  Inner tube is adjustable so that you can match coupler height to application.  Outer tube welds onto trailer, and the inner tube slides up or down for proper positioning.

• 2 5/16″  Ball size
• 29 1/2″ Length not adjusted
• 37 1/2″ Length fully adjusted
• 4 1/2″ outer diameter on outer tube
• 4″ outer diameter on inner tube
• 25,000lb Capacity
